Pars Process Integrated system of fire protection and alarm barking
Introducing:
Alarm system and remote monitoring, intelligent and interactive Pars processing using Compact Scada systems, alarm and sensor malfunction with the device locally or remotely via the color display and enables the central system .
The system through the network node supports four segments and each segment according to the node number is 120, node 480 is provided to manage.
Each node includes a normal sensor from different samples or the non-addressable sensors that are used old and is addressable by a small converter, and is connected to the center and the possibility of reading the usual sensors with smoke, heat and radiation (IR) is provided and graphically display the entire place to monitor and display the status of each point.
With this intelligent scheduling system, the number of notifications and different scenarios can be defined for each scenario, except for warnings, introduced special functions (such as input fuel cut, opening the gates for entrance ways emergency exits, ...)
Features & Benefits:
General Specifications:
- Have the ability to work with non-addressable converters old through his placement converters per sensor
- Capable of operating from -10 to +70 ° C temperature
- The implementation is based on standard protocols and reliable Fieldbus
- Local management Compact SCADA System
Smart and network capabilities:
- Or view the output for large systems or remote network
- Networking capabilities in larger systems up to 4096 zones per segment
- Smart programming capabilities to detect alarms and automatic operation in case of detection alarms Positive Negative
Profile Input - Output:
- 16 direct input sensor types
- 4 zone 128 zone sensor input directly or in the form of a tree
- Up to 180 addressable sensor input
- The definitive diagnosis of each sensor
- 16 direct outputs alarms
- Ability to define alarms by zone and type siren cut
- The use of temperature sensors per sensor for the detection of alarms Negative
Block Diagram:
